جديدة ماكينة البلوك Constmach BS-30 Briquette Making Machine (Concrete Block Making Machine)

You can call us 24/7 for the briquette making machine (concrete block making machine) for sale.

Our BS-30 Briquette Making Machine is revolutionizing the production of building materials in an efficient way. This high-tech machine combines innovation with speed and reliability, perfectly simplifying the production process of interlocking blocks and brick parts.

At the heart of the BS-30's capabilities is the ability to produce 30 locked parts per pallet in just 30 seconds and 10 block parts in just 23 seconds. These characteristics make it a powerhouse in the field of productivity. Its powerful hydraulic pump provides a flow rate of 60 liters per minute, which guarantees consistent performance, and has a cooling capacity of 90 liters per minute, supported by a compact but powerful 0.18 kW motor.

Our precision engineered machine has Tellus 46 brand hydraulic system features equipped with 250 liter oil capacity and is supported by 120 bar working pressure. This is complemented by a vibration compression force of 15,000 kg, which is designed to effectively compress materials.

Structurally, the BS-30 is designed for durability; the machine, measuring 2.2x7x2.5 meters and weighing 9,000 kg, is equipped with a 650 kg Lock Die produced by oxygen cutting and CNC milling, and a 500 kg corrosion plate containing a laser cutting system.

The control is simplified through a Schneider PLC system with a 7-inch touch screen, which provides easy operation and precise control over every aspect of the production process. The durability of our machine is further increased in the mixer section with corrosion-protected sheet metal made of ST52 steel, which provides long-lasting reliability in all conditions.

The BS-30 Briquette Making Machine not only offers superior performance, but also promises a smooth operational experience, so it is an ideal choice for anyone who wants to upgrade their production capabilities, without specifying the construction industry directly. Invest in BS-30 today and step into a new era of building material production where efficiency and innovation meet.

Technical Characteristics of BS-30 Briquette Making Machine

Machine Specifications

Interlock Quantity and Printing Time: 30 pcs locking, 30 seconds printing time

Block Parts and Printing Time: 10 blocks, 23 seconds printing time

Pump Power: 60 lt/min, Efficiency: 0.98

Hydraulic Cooler Capacity: 90 lt/min, 0.18 kW

Hydraulic System Brand and Oil Capacity: Tellus 46, 250 lt

Machine Working Hydraulic Pressure: 120 bar

Vibration Compression Strength: 15,000 kg

Machine Size and Weight: 2.2 x 7 x 2.5 m, 9000 kg

Lock Mold Specifications: Oxygen cutting and CNC Milling, 650 kg

Block Mold Specifications: Corrosion plate, laser cutting system, 500 kg

Stacking Robot

Pump Power: 21 lt/min x 2

Robot Size and Weight: 1.45 x 3 x 1.5 m, 1500 kg

Electrical Control

PLC, Module and Display: Schneider, 7 inch touch screen

Thermal and Conductor Brand: Schneider (France), Weid Moeller (Germany)

Mortar Band

Size and Weight: 8 m length, 70 cm width, 1000 kg

The Mixer

Mixer Capacity: 7500 dm3

Mixing Process: 1200 kg sand, 190 kg cement, 75 kg water; Average time: 2.5 minutes

Corrosion Protection Sheet: 15 mm thickness, st52 steel

Mixer Motor Power and Torque: 18.5 kW, 40 rpm x 2 pcs, 11500 Nm

Sand Band

Size and Weight: 10 m length, 60 cm width, 1000 kg

Aggregate Hopper and Weight Band

Hopper Capacity and Weight: 15 m3 x 4 pcs, 6200 kg

Valve Type and Power: Vibration system, 0.5 kW x 4

Band Size and Weight: 10 m length, 60 cm width, 1000 kg

Cement Silos And Equipment

Silo Capacity and Weight: 45 tons, 5500 kg

Silo Dimensions: Diameter: 2250 mm, Height: 11500 mm

Cement Weight Characteristics: 300 kg

Load Cell Brand and Capacity: ESIT, 500 kg

Extra Features: Safety valve, 24 m2 open area filter (airjetplus)
